High Efficiency ZXW590X110 Mining Vibrating Feeder

Technical Parameters

Model: ZSW590X110

Max Feed Size: 600mm

Processing Capacity: 250-450t/h

Motor Power: 22kw

Technical Parameters

Technical Parameters Of Suspended Feeder

Profile
ZSW series round vibratory feeder is the latest super short linear vibration feeder, which was designed by our company to transport bulk material evenly to coarse crusher in crushing and screening station. The series of products have complete specifications, firm structure, impact resistance, and reliable operation. In order to ensure continuous and uniform feeding for the crusher, the material can be sifted effectively, which makes the system more economical and reasonable in configuration. It is necessary equipment for crushing and screening.

Working Principle

Vibrating Feeder is composed of a feed chute, a vibration exciter, spring supports and a transmission device. The vibration exciter, consisting of two eccentric shafts (driving shaft and driven shaft) and gear pair, vibrates the feed chute. Driven by the motor, the driving shaft works under the action of the triangular belt. Next, gears on the driving shaft rotates the driven shaft. So, the rotation direction of driven shaft shall be contrary to that of driving shaft. In the process, the chute vibrates to convey materials continuously.
