SG1530-4 Fine Sand Recycling Machine

Technical Parameters

Model: 1530-4

Processing capacity: 180-200t/h

Vibration power: 2*3kw

Pump power: 2*18.5kw

Concentrator: 300mm*4

Model Technical Parameters
Note: The pump is divided into the vertical pump and horizontal pump, after treatment, solid particles above 200 mesh and solid content 70%-80%.
The treatment capacity (treatability) varies according to the solid content.

Equipment Principle
The equipment consists of a motor, wear-resistant pump, mortar concentrator, cleaning tank of straight-line dehydration screen, reverse box, and so on.
Working process: the mud water flows into the cleaning tank, through the wear-resistant pump, and arrive at the mortar concentrator, separate the sewage and sand by the concentrator, and the sand passes through the spray head and come to the dehydration screen, arrive into the conveyor belt after dehydration. The sewage returns to the reverse box, split flows into the cleaning tank, and the excess part leaks out.

Hydrocyclone is mainly used in mineral processing
1 Heavy-medium cyclone is the common heavy-medium separation equipment.
2 As grading equipment in grinding circuit, especially as grading equipment for fine grinding.
3. Desliming and concentrating ore pulp.
